sino po merong design ng AMP based sa specs:
AMP - 1 - Used in line array setups with dual or quad 18inch subs etc.
P13,500
Custom mono block board amp taken from various designs @ Superb Class AB operation.
Fet inputs. - serious high end it can go up to 2kw! - built for real THX ultra 2 cinema
Specification:
prim input 220volts secondary 48-0-48 = 96 Vrms = Vpp/ 2*(squareroot of 2) /2.8
96V/2.8 = 33.94Vrms
A 36amp monster ie core transformer!
DC rail voltage is 96 X 1.414vdc = 136vdc two of these in bridge mode is 272vdc
Twin 100v/total 10000 microfarad capacitors.
Final RMS output - 300-2kwatts @ 8/4/2/1ohm
8pcs 2sc2922e and 8pcs 2sa1216 w/ split 48/36amps a 68lbs transformer
Triple Darlington drivers.
16 TB34 final stage power output transistors.
optional casing add 2k.
AMP - 2 Used in line array setups with dual 15inch subs etc. Built for mobile setup or outdoor concerts.
P10,500
same board as amp1
Specification:
prim input 220volts secondary 38-0-38 x 1.414vdc @ 20amp transformer!
Twin 63v/total 10000 microfarad capacitors.
Final RMS output - 250-1300watts @ 8/4/2/1ohm
8 TB34 final stage power output transistors.
4pcs 2sc2922e and 4pcs 2sa1216 w/ split 38/20amps transformer
optional casing add 2k.
AMP3 - best for HIGHEND subwoofer w/ 2kw to 4kw peak Final RMS output - 200-800watts @ 8/4/2/1ohm
Specification:
6.5k 4ohm LF steady 8total 4pcs 2SB817 and 4pcs 2SD1047 w/ split 38/12amps transformer
7.5k 4ohm LF w/fullrange 4total 2pcs 2sc2922 and 2pcs 2sa1216 w/ split 38/12amps transformer
7.5k 2ohm LF steady 8total 4pcs 2sa1943 and 4pcs 2sc5200 w/ split 38/12amps transformer
optional +1k for amp2 transformer 38/20ampere.
optional casing add 1k.
AMP4 - best for subwoofer or full range w/ 1kw to 2kw peak Final RMS output - 150-700watts @ 8/4/2/1ohm w/gain control
Specification:
4,500 basic - 4ohm LF steady 2pcs 2SB817 and 2pcs 2SD1047 w/ split 36/6amps transformer
4,750 v2 - 2ohm LF steady 2pcs 2sa1943 and 2pcs 2sc5200 w/ split 36/6amps transformer
3,000 4.5 - 4ohm LF steady 1pc 2SB817 and 1pc 2SD1047 w/ split 24/3amps if 2ch 24/6amps transformer
3,500 4.5v2 - 2ohm steady 1pc 2sa1943 and 1pc 2sc5200 w/ split 24/6amps transformer
optional casing add 1k.
